AUTOMAT.MELTING POINT WRS-2A *

Specifications

For the simultaneous analysis of 3 samples.
Graphical LCD display and 16-key numeric keyboard.
Determination of melting point by photoelectric detection.
Automatic function for reading and recording initial and final melting points, melting curves, and calculation of average value.

Digital LCD Display: Numeric and Graphical
Maximum capacity of capillary tubes of 1.4 mm Ø ext.: 3
Temperature range: from 50 ºC to 300 ºC
Temperature reading resolution: 0.1ºC
Melting point measurement accuracy: up to 200 ºC ±0.5 ºC and from 200 ºC to 300 ºC ±0.8 ºC
Selectable measuring ramps (in ºC/minutes): 0.2 - 0.5 - 1 - 1.5 - 2 - 3 - 4 and 5 ºC/min.
Repeatability: 0.3 ºC in 1 ºC/min ramps; 0.2 ºC in 0.2 ºC/min ramps.
Sample holder: for capillary tubes of 1.4 mm Ø ext. / 1 mm Ø int.
Sample filling height: 3mm
Power supply voltage: 220V-50/60Hz
Power consumption: 110W
